BESV PREMIUM E-BIKE

TR-B 1.3 LS

The TR-B 1.3 LS combines the versatility of the TR-B 1.3 with a low-step frame design, making it perfect for riders seeking both convenience and performance. It’s powered by the Bosch Performance line center-motor and features a 625 Wh Bosch Power Tube battery. Besides this, It’s equipped with a Shimano CUES RD-U6020, 11 speed derailleur and Schwalbe Energizer tires for great traction.

SIZE

XS (43cm)| S (47cm)| M (52cm)| L (56cm)

COLOR

Metallic titanium with black gloss

PRICE

€4.699,00

FRAME OPTIONS

WHERE TO BUY

DESCRIPTION

Easy Access & Versatility
Adventure-Ready Battery
High-Quality Components

Specifications

FRAMESET	FRAME BESV TR-B 1.Series full smooth welded alloy frame, Bosch motor and internal battery compatible COLOR(S) Metallic titanium with black gloss SIZES XS (43cm), S (47cm), M (52cm), L (56cm) FORK SR Suntour Mobie25, Lockout, Air damping, tapered alloy steerer, travel 75mm, Thru-axle REAR CARRIER Tubular aluminium carrier, with MIK HD platform and spring clamp, H-Cargo rear light mount FENDERS Alloy extruded fenders, front & rear 3/4 length, stainless steel hardware
DRIVETRAIN	MOTOR Bosch Performance Line GEN3 (75Nm) BATTERY 625 Wh Bosch Power Tube, with 4A charger DISPLAY Bosch Kiox with LED display and Bluetooth connectivity REAR DERAILLEUR Shimano CUES RD-U6020, 11 speed CASSETTE Shimano CUES CS-LG400, 11 speed, 11-45T CHAIN Shimano CN-LG500, with Quick-Link CRANKSET Samox for Bosch, 38T chainring BOTTOM BRACKET Bosch, integrated in motor
COCKPIT	HANDLEBAR Alloy City-Trekking rise bar, 6066 alloy, 40mm rise, sweep: 20° up, 31.8mm clamp STEM 3D Forged alloy Trekking stem, adjustable 0-90°, 31.8mm clamp HEADSET Acros, AZX-585, 1.5" headset, angular contact bearings, integrated cable routing GRIPS Comfortable gel grips with padding SHIFTERS Shimano CUES SL-U6000, 11 speed SADDLE Selle Italia Max S5 Superflow SEATPOST Promax SP-726, 31.6mm diameter PEDALS Wellgo pedals with reflectors
WHEELS	WHEEL SET Shimano HB-TC500-15 front hub and FH-TC500-HM-B rear hub, 700c multichamber alloy rims 36H TIRES Schwalbe Energizer Plus Tour, 55×622, Addix E, Twin Skin, 67 TPI wire bead with puncture protection, reflective stripe

Specifications are subject to errors.

Discover features

Geometry

	xs	s	m	l
Rider Height	150-165 cm	164-175 cm	175-188 cm	187-198 cm
1. Top Tube Length	580	586	600	610
2. Frame Reach	390	390	395	409
3. Stack	661	665	670	675
4. Stand over height	419	419	419	419
5. Wheel Base	1144	1144	1156	1172
6. Head Tube Length	155	160	170	170
7. Head Tube Angle	68.5°	68.5°	68.5°	68.5°
8. Seat Tube Angle	74°	73°	73°	73°
9. Seat Tube Length	430	470	520	560
10. Chainstay Length	485	485	485	485
11. BB Drop	75	75	75	75

what's your size

Downloads

NAME	TYPE	DATE
SPECIFICATION SHEET	PDF	30/10/2023
DECLARATION OF CONFORMITY	PDF	22/12/2023
BATTERY	ZIP	16/10/2023
